Superoll Head - Hutchison Tool

Superoll heads are adjustable to 0.001 inches (0.025 mm). An assortment of Superoll heads are available for processing OD surfaces up to 26 mm in diameter.

Category: Superoll Mugen

Model #	Tool Diameter - A (Adjustment)	Roller Model	Roller Quantity	Head Part Number	List Price
SO300-LE	0.120 ~ 0.109 inches (3.05 ~ 2.75 mm)	SPMR 4 x 15	3	SPMH300	QUOTE
SO325-LE	0.129 ~ 0.119 inches (3.30 ~ 3.00 mm)	SPMR 4 x 15	3	SPMH325	QUOTE
SO350-LE	0.139 ~ 0.128 inches (3.55 ~ 3.25 mm)	SPMR 4 x 15	3	SPMH350	QUOTE
SO375-LE	0.149 ~ 0.138 inches (3.80 ~ 3.50 mm)	SPMR 4 x 15	3	SPMH375	QUOTE
SO400-LE	0.159 ~ 0.148 inches (4.05 ~ 3.75 mm)	SPMR 4 x 15	3	SPMH400	QUOTE
SO425-LE	0.169 ~ 0.158 inches (4.30 ~ 4.00 mm)	SPMR 4 x 15	3	SPMH425	QUOTE
SO450-LE	0.179 ~ 0.168 inches (4.55 ~ 4.25 mm)	SPMR 4 x 15	3	SPMH450	QUOTE
SO475-LE	0.188 ~ 0.178 inches (4.80 ~ 4.50 mm)	SPMR 4 x 15	3	SPMH475	QUOTE
SO500-LE	0.198 ~ 0.188 inches (5.05 ~ 4.75 mm)	SPMR 4 x 15	3	SPMH500	QUOTE
SO525-LE	0.208 ~ 0.197 inches (5.30 ~ 5.00 mm)	SPMR 4 x 15	3	SPMH525	QUOTE
SO550-LE	0.218 ~ 0.207 inches (5.55 ~ 5.25 mm)	SPMR 4 x 15	3	SPMH550	QUOTE
SO575-LE	0.228 ~ 0.217 inches (5.80 ~ 5.50 mm)	SPMR 4 x 15	3	SPMH575	QUOTE
SO600-LE	0.238 ~ 0.227 inches (6.05 ~ 5.75 mm)	SPMR 4 x 15	5	SPMH600	QUOTE
SO625-LE	0.248 ~ 0.237 inches (6.30 ~ 6.00 mm)	SPMR 4 x 15	5	SPMH625	QUOTE
SO650-LE	0.257 ~ 0.247 inches (6.55 ~ 6.25 mm)	SPMR 4 x 15	5	SPMH650	QUOTE
SO675-LE	0.267 ~ 0.256 inches (6.80 ~ 6.50 mm)	SPMR 4 x 15	5	SPMH675	QUOTE
SO700-LE	0.277 ~ 0.266 inches (7.05 ~ 6.75 mm)	SPMR 4 x 15	5	SPMH700	QUOTE
SO725-LE	0.287 ~ 0.276 inches (7.30 ~ 7.00 mm)	SPMR 4 x 15	5	SPMH725	QUOTE
SO750-LE	0.297 ~ 0.286 inches (7.55 ~ 7.25 mm)	SPMR 4 x 15	5	SPMH750	QUOTE
SO775-LE	0.307 ~ 0.296 inches (7.80 ~ 7.50 mm)	SPMR 4 x 15	5	SPMH775	QUOTE
SO800-LE	0.316 ~ 0.306 inches (8.05 ~ 7.75 mm)	SPMR 5 x 20	5	SPMH800	QUOTE
SO825-LE	0.326 ~ 0.315 inches (8.30 ~ 8.00 mm)	SPMR 5 x 20	5	SPMH825	QUOTE
SO850-LE	0.336 ~ 0.325 inches (8.55 ~ 8.25 mm)	SPMR 5 x 20	5	SPMH850	QUOTE
SO875-LE	0.346 ~ 0.335 inches (8.80 ~ 8.50 mm)	SPMR 5 x 20	5	SPMH875	QUOTE
SO900-LE	0.356 ~ 0.345 inches (9.05 ~ 8.75 mm)	SPMR 5 x 20	5	SPMH900	QUOTE
SO925-LE	0.366 ~ 0.355 inches (9.30 ~ 9.00 mm)	SPMR 5 x 20	5	SPMH925	QUOTE
SO950-LE	0.375 ~ 0.365 inches (9.55 ~ 9.25 mm)	SPMR 5 x 20	5	SPMH950	QUOTE
SO975-LE	0.358 ~ 0.375 inches (9.80 ~ 9.50 mm)	SPMR 5 x 20	5	SPMH975	QUOTE
SO1000-LE	0.395 ~ 0.384 inches (10.05 ~ 9.75 mm)	SPMR 5 x 20	5	SPMH1000	QUOTE
SO1025-LE	0.405 ~ 0.394 inches (10.30 ~ 10.00 mm)	SPMR 5 x 20	5	SPMH1025	QUOTE
SO1050-LE	0.415 ~ 0.404 inches (10.55 ~ 10.25 mm)	SPMR 5 x 20	5	SPMH1050	QUOTE
SO1075-LE	0.425 ~ 0.414 inches (10.80 ~ 10.50 mm)	SPMR 5 x 20	5	SPMH1075	QUOTE
SO1100-LE	0.435 ~ 0.424 inches (11.05 ~ 10.75 mm)	SPMR 5 x 20	5	SPMH1100	QUOTE
SO1125-LE	0.444 ~ 0.434 inches (11.30 ~ 11.00 mm)	SPMR 5 x 20	5	SPMH1125	QUOTE
SO1150-LE	0.454 ~ 0.443 inches (11.55 ~ 11.25 mm)	SPMR 5 x 20	5	SPMH1150	QUOTE
SO1175-LE	0.464 ~ 0.453 inches (11.80 ~ 11.50 mm)	SPMR 5 x 20	5	SPMH1175	QUOTE
SO1200-LE	0.474 ~ 0.463 inches (12.05 ~ 11.75 mm)	SPMR 6 x 20	5	SPMH1200	QUOTE
SO1225-LE	0.484 ~ 0.473 inches (12.30 ~ 12.00 mm)	SPMR 6 x 20	5	SPMH1225	QUOTE
SO1250-LE	0.494 ~ 0.483 inches (12.55 ~ 12.25 mm)	SPMR 6 x 20	5	SPMH1250	QUOTE
SO1275-LE	0.503 ~ 0.493 inches (12.80 ~ 12.50 mm)	SPMR 6 x 20	5	SPMH1275	QUOTE
SO1300-LE	0.513 ~ 0.502 inches (13.05 ~ 12.75 mm)	SPMR 6 x 20	5	SPMH1300	QUOTE
SO1325-LE	0.523 ~ 0.512 inches (13.30 ~ 13.00 mm)	SPMR 6 x 20	5	SPMH1325	QUOTE
SO1350-LE	0.533 ~ 0.522 inches (13.55 ~ 13.25 mm)	SPMR 6 x 20	5	SPMH1350	QUOTE
SO1375-LE	0.543 ~ 0.532 inches (13.80 ~ 13.50 mm)	SPMR 6 x 20	5	SPMH1375	QUOTE
SO1400-LE	0.553 ~ 0.542 inches (14.05 ~ 13.75 mm)	SPMR 6 x 20	5	SPMH1400	QUOTE
SO1425-LE	0.562 ~ 0.552 inches (14.30 ~ 14.00 mm)	SPMR 6 x 20	5	SPMH1425	QUOTE
SO1450-LE	0.572 ~ 0.562 inches (14.55 ~ 14.25 mm)	SPMR 6 x 20	5	SPMH1450	QUOTE
SO1475-LE	0.582 ~ 0.571 inches (14.80 ~ 14.50 mm)	SPMR 6 x 20	5	SPMH1475	QUOTE
SO1500-LE	0.592 ~ 0.581 inches (15.05 ~ 14.75 mm)	SPMR 6 x 20	7	SPMH1500	QUOTE
SO1525-LE	0.602 ~ 0.591 inches (15.30 ~ 15.00 mm)	SPMR 6 x 20	7	SPMH1525	QUOTE
SO1550-LE	0.366 ~ 0.355 inches (9.30 ~ 9.00 mm)	SPMR 5 x 20	5	SPMH925	QUOTE
SO1575-LE	0.375 ~ 0.365 inches (9.55 ~ 9.25 mm)	SPMR 5 x 20	5	SPMH950	QUOTE
SO1600-LE	0.358 ~ 0.375 inches (9.80 ~ 9.50 mm)	SPMR 5 x 20	5	SPMH975	QUOTE
SO1625-LE	0.395 ~ 0.384 inches (10.05 ~ 9.75 mm)	SPMR 5 x 20	5	SPMH1000	QUOTE
SO1650-LE	0.405 ~ 0.394 inches (10.30 ~ 10.00 mm)	SPMR 5 x 20	5	SPMH1025	QUOTE
SO1675-LE	0.415 ~ 0.404 inches (10.55 ~ 10.25 mm)	SPMR 5 x 20	5	SPMH1050	QUOTE
SO1700-LE	0.425 ~ 0.414 inches (10.80 ~ 10.50 mm)	SPMR 5 x 20	5	SPMH1075	QUOTE
SO1725-LE	0.435 ~ 0.424 inches (11.05 ~ 10.75 mm)	SPMR 5 x 20	5	SPMH1100	QUOTE
SO1750-LE	0.444 ~ 0.434 inches (11.30 ~ 11.00 mm)	SPMR 5 x 20	5	SPMH1125	QUOTE
SO1775-LE	0.454 ~ 0.443 inches (11.55 ~ 11.25 mm)	SPMR 5 x 20	5	SPMH1150	QUOTE
